| Brand Name: | Genyu |
| Model Number: | GY-TFT096B013 |
| MOQ: | 1000 pieces |
| Price: | Negotiable |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram, Credit Card |
| Supply Ability: | 300K pcs/ Month |
0.96 Inch TFT LCD Display IPS 80x160 Dots 8pin FPC ST7735 driver 4-line Serial
A 0.96-inch TFT LCD is a small, full-color display that typically uses a Thin-Film Transistor (TFT) technology for better image quality and faster refresh rates.
Basic Parameters:
| NO. | ITEM | SPECIFICATIONS |
| 1 | Product Name | 0.96 Inch TFT LCD |
| 2 | LCD Type | IPS |
| 3 | Viewing Angle | Free |
| 4 | Resolution |
80x160 dots
|
| 5 | Working Voltage | 2.8V (Typ.) |
| 6 | Operating Temperature | -20~+70℃ |
| 7 | Storage Temperature | -30~+80℃ |
| 8 | FPC Connector | 8PIN, ZIF type |
| 9 | Pitch | 0.5 mm |
| 10 | Driver IC(COG) | ST7735S |
| 11 | Interface | 4 SPI |
| 12 | Backlight Type | 1-LED, White |
| 13 | Power Consumption | VF=3.2V, IF=15mA |
| 14 | Outline Dimension | 14.04(W)* 27.95(H)* 1.73(T) mm |
| 15 | Active Area | 10.8(W)* 21.7(H) mm |
TFT Screens ( 0.96 inch~10.1 inch )
We mainly develop TFT LCD screens of small-middle sizes, including 0.96", 1.06", 1.14", 1.28", 1.3", 1.44", 1.54", 1.69", 1.77", 1.83", 1.99", 2.0", 2.2", 2.4", 2.8", 2.95", 3.13", 3.2", 3.5", 3.97", 4.3", 5", 5.5", 7", 8" and 10.1", etc.
Common applications of the 0.96-inch TFT display:
1. Wearable Devices
Smartwatches: Ideal for low-cost, compact smartwatches that need a small color display for time, health data, and notifications.
Fitness Trackers: Useful for displaying step counts, heart rate data, or workout information in compact, low-power wearable devices.
2. Portable Devices
Handheld Devices: Used in handheld digital meters, data loggers, or portable testers that need to show measurements, data trends, or diagnostic information.
Game Consoles: In small, portable retro gaming consoles where a small color display is needed for graphics and menus.
3. IoT Devices
IoT Sensors: In the Internet of Things (IoT) devices, this small TFT display is often used to show status, connectivity, or sensor data, such as weather conditions, air quality, or device health status.
Smart Home Devices: In smart thermostats or home automation hubs, a 0.96-inch TFT can display settings, device status, or system information.
A. Our office is in Shenzhen, Guangdong and our factory is in Jiangxi Province.
5. Q: Can I get a lower price for TFT LCD?
A: Yes, cheaper price with bigger/larger quantities order.
6. Q: How do you control the quality of products?
A: All products are 100% inspected before shipment.
7. Q: Can you provide the technical support?
A: Yes, We will provide detailed specifications and initialization code.
