| Brand Name: | Genyu |
| Model Number: | GY07800NM-14 |
| MOQ: | 4000 pieces |
| Price: | Negotiation |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram, Credit Card |
| Supply Ability: | 500K pcs/ Month |
Advantages of Segment LCDs in Thermostats:
Clear Readability: The segmented design of the display makes it easy to read temperature settings, even from a distance.
Simplicity: These displays are straightforward and user-friendly, offering just the right amount of information needed (e.g., temperature, mode) without unnecessary complexity.
Energy Efficiency: Ideal for devices like programmable thermostats or smart thermostats that need to be power-efficient.
Cost-Effective: Segment LCDs are often more affordable to manufacture compared to more complex displays (e.g., full-color or touch screens), making them a popular choice in budget-friendly or mid-range thermostat models.
Detailed Parameters:
| Model number | GY07800NM-14 | LCD type | Segmented Display |
| Outline Dimension | 57(W)* 29.2(H)* 2.0(T) mm | Display mode | VA, Negative |
| LCD viewing area | 51(W)* 26(H) mm | Polarizer type | Transmissive |
| Driver IC | / | LED backlight | White |
| Drive method | 1/4 Duty, 1/3 Bias | Working voltage | 5.0V |
| Viewing angle | 12 O'clock | Connection Way | PIN, 17 numbers |
| Operate temperature | -20℃~+70℃ | Storage temperature | -30~+80℃ |
Common Applications of Segment LCDs in Thermostats:
Home Thermostats: Used in wall-mounted thermostats to control heating, cooling, and air conditioning systems in residential homes.
Smart Thermostats: Although many smart thermostats use full-color touchscreens, some models still utilize segment LCDs to display basic information like current temperature, setpoint, and mode.
Industrial and Commercial Thermostats: Segment LCDs are often used in programmable thermostats designed for commercial buildings, HVAC systems, and industrial environments where simplicity and clarity are prioritized.
Portable Thermostats: In battery-operated or portable devices, segment displays are ideal due to their energy efficiency and clear readability.
HVAC Controllers: Segment LCDs are also commonly used in control panels for HVAC systems, providing users with easy-to-read feedback about system settings and temperature.
1. Q: What products can you provide?
A. 1) Custom Segment LCD Display;
2) Monochrome Graphic/Dot Matrix LCD Display Modules;
3) Micro OLED Display Modules;
4) Color TFT LCD Display Panels;
5) LED Backlights.
2. Q: What is the process for custom samples?
A: Send inquiry -- Offer quotation -- Confirm quotation & Pay tooling charge -- Provide drawing -- Confirm drawing -- Make tooling & samples -- Samples finished -- Delivery via freight or sea collect.
3. Q: How long can I get the custom samples?
A: Different product types will take different times. Usually, it will take about 30-35 days.
4. Q: Can I get free samples?
A: We would like to provide 3-5 pcs free samples after tooling.
5. Q: What is the minimum order quantity?
A: MOQ mainly depends on LCD sizes.
6. Q: How long is it for mass production?
A: Usually 35-45 days, it depends on your part number.
7. Q: How do you control the quality of products?
A: All products are 100% inspected before shipment.
